工业缓冲器 PowerStop
High Energy 系列

以最高产品质量满足超常的应用要求和负荷
通过各个活塞位置上的最佳负荷系数实现高能量吸收
通过逐渐变细的螺旋槽实现振动最小化以及精确制动
凭借流体静力活塞导向实现磨损最小化
高运行安全性和可靠性
通过采用不锈钢材料确保防锈蚀能力
针对客户定制的解决方案进行个性化设计

概览

订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
螺纹: M8X1.0
PHE08X10NHDD-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHDE-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHDS-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHDK-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHFD-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHFE-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHFS-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHFK-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHAD-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHAE-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHAS-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHAK-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHBS-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NHBK-A	4 [J]	0.1 [m/s]	1.2 [m/s]
PHE08X10NMDD-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMDE-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMDS-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMDK-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMFD-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMFE-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMFS-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMFK-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMAD-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMAE-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMAS-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMAK-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMBS-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NMBK-A	4 [J]	0.8 [m/s]	2.2 [m/s]
PHE08X10NSDD-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSDE-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSDS-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSDK-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSFD-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSFE-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSFS-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSFK-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSAD-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSAE-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSAS-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSAK-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSBS-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NSBK-A	3.5 [J]	1.8 [m/s]	3.5 [m/s]
PHE08X10NWDD-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWDE-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWDS-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWDK-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWFD-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWFE-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWFS-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWFK-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWAD-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWAE-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWAS-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWAK-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWBS-A	3.5 [J]	3 [m/s]	5 [m/s]
PHE08X10NWBK-A	3.5 [J]	3 [m/s]	5 [m/s]

螺纹: M10X1
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE10X10NHDD-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHDE-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHDS-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHDK-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHFD-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHFE-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHFS-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHFK-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHAD-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHAE-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHAS-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHAK-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHBS-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NHBK-A	10 [J]	0.1 [m/s]	1.2 [m/s]
PHE10X10NMDD-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMDE-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMDS-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMDK-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMFD-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMFE-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMFS-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMFK-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMAD-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMAE-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMAS-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMAK-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMBS-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NMBK-A	10 [J]	0.8 [m/s]	2.2 [m/s]
PHE10X10NSDD-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSDE-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSDS-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSDK-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSFD-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSFE-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSFS-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSFK-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NWAD-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NSAD-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSAE-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSAS-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSAK-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSBS-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NSBK-A	9 [J]	1.8 [m/s]	3.5 [m/s]
PHE10X10NWDD-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWDE-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWDS-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWDK-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWFD-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWFE-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWFS-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWFK-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWAE-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWAS-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWAK-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWBS-A	9 [J]	3 [m/s]	5 [m/s]
PHE10X10NWBK-A	9 [J]	3 [m/s]	5 [m/s]

螺纹: M12X1
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE12X10NHDD-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHDE-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHDS-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHDK-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHFD-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHFE-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHFS-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHFK-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHAD-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHAE-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHAS-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHAK-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHBS-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NHBK-A	18 [J]	0.1 [m/s]	1.2 [m/s]
PHE12X10NMDD-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMDE-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMDS-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMDK-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMFD-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMFE-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMFS-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMFK-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMAD-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMAE-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMAS-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMAK-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMBS-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NMBK-A	18 [J]	0.8 [m/s]	2.2 [m/s]
PHE12X10NSDD-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSDE-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSDS-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSDK-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSFD-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSFE-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSFS-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSFK-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSAD-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSAE-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSAS-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSAK-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSBS-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NSBK-A	16 [J]	1.8 [m/s]	3.5 [m/s]
PHE12X10NWDD-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWDE-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWDS-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWDK-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWFD-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWFE-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWFS-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWFK-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWAD-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWAE-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWAS-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWAK-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWBS-A	16 [J]	3 [m/s]	5 [m/s]
PHE12X10NWBK-A	16 [J]	3 [m/s]	5 [m/s]

螺纹: M14X1
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE14X10NHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHBS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NHBK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10NMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMBS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NMBK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10NSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSBS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NSBK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10NWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWAK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWBS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10NWBK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X10LMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X10LSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X10LWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X10LWAK-A	28 [J]	3 [m/s]	5 [m/s]

螺纹: M14X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE14X15NHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHBS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NHBK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15NMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMBS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NMBK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15NSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSBS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NSBK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15NWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWAK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWBS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15NWBK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE14X15LMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE14X15LSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE14X15LWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE14X15LWAK-A	28 [J]	3 [m/s]	5 [m/s]

螺纹: M16X1
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE16X10NHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10NMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10NSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10NWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10NWAK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X10LMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X10LSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X10LWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X10LWAK-A	28 [J]	3 [m/s]	5 [m/s]

螺纹: M16X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE16X15NHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15NMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15NSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15NWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15NWAK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LHDD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHDE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHDS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHDK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHFD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHFE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHFS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHFK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHAD-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHAE-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHAS-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LHAK-A	34 [J]	0.1 [m/s]	1.2 [m/s]
PHE16X15LMDD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMDE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMDS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMDK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMFD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMFE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMFS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMFK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMAD-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMAE-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMAS-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LMAK-A	32 [J]	0.8 [m/s]	2.2 [m/s]
PHE16X15LSDD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSDE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSDS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSDK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSFD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSFE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSFS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSFK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSAD-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSAE-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSAS-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LSAK-A	30 [J]	1.8 [m/s]	3.5 [m/s]
PHE16X15LWDD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWDE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWDS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWDK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWFD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWFE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWFS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWFK-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWAD-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWAE-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWAS-A	28 [J]	3 [m/s]	5 [m/s]
PHE16X15LWAK-A	28 [J]	3 [m/s]	5 [m/s]

螺纹: M20X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE20X15NHDD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHDE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHDS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHDK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHFD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHFE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHFS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHFK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHAD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHAE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHAS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHAK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHBS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NHBK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15NMDD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMDE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMDS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMDK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMFD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMFE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMFS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMFK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMAD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMAE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMAS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMAK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMBS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NMBK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15NSDD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSDE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSDS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSDK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSFD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSFE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSFS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSFK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSAD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSAE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSAS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSAK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSBS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NSBK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15NWDD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWDE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWDS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWDK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWFD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWFE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWFS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWFK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWAD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWAE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWAS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWAK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWBS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15NWBK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LHDD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHDE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHDS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHDK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHFD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHFE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHFS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHFK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHAD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHAE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHAS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LHAK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE20X15LMDD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMDE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMDS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMDK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMFD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMFE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMFS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMFK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMAD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMAE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMAS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LMAK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE20X15LSDD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSDE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSDS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSDK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSFD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSFE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSFS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSFK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSAD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSAE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSAS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LSAK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE20X15LWDD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWDE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWDS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWDK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWFD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWFE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWFS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWFK-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWAD-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWAE-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWAS-A	65 [J]	3 [m/s]	5 [m/s]
PHE20X15LWAK-A	65 [J]	3 [m/s]	5 [m/s]

螺纹: M22X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE22X15NHDD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHDE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHDS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHDK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHFD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHFE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHFS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHFK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHAD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHAE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHAS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NHAK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15NMDD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMDE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMDS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMDK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMFD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMFE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMFS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMFK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMAD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMAE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMAS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NMAK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15NSDD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSDE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSDS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSDK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSFD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSFE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSFS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSFK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSAD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSAE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSAS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NSAK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15NWDD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWDE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWDS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWDK-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWFD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWFE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWFS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWFK-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWAD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWAE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWAS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15NWAK-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LHDD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHDE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHDS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHDK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHFD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHFE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHFS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHFK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHAD-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHAE-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHAS-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LHAK-A	80 [J]	0.1 [m/s]	1.2 [m/s]
PHE22X15LMDD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMDE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMDS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMDK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMFD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMFE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMFS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMFK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMAD-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMAE-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMAS-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LMAK-A	75 [J]	0.8 [m/s]	2.2 [m/s]
PHE22X15LSDD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSDE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSDS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSDK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSFD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSFE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSFS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSFK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSAD-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSAE-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSAS-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LSAK-A	70 [J]	1.8 [m/s]	3.5 [m/s]
PHE22X15LWDD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWDE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWDS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWDK-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWFD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWFE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWFS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWFK-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWAD-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWAE-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWAS-A	65 [J]	3 [m/s]	5 [m/s]
PHE22X15LWAK-A	65 [J]	3 [m/s]	5 [m/s]

螺纹: M25X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE25X15NHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHBS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NHBK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15NMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMBS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NMBK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15NSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSBS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NSBK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15NWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWAK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWBS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15NWBK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE25X15LMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE25X15LSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE25X15LWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE25X15LWAK-A	170 [J]	3 [m/s]	5 [m/s]

螺纹: M27X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE27X15NHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15NMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15NSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15NWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15NWAK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X15LMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X15LSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X15LWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X15LWAK-A	170 [J]	3 [m/s]	5 [m/s]

螺纹: M27X3.0
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE27X30NHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30NMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30NSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30NWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30NWAK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LHDD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHDE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHDS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHDK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHFD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHFE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHFS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHFK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHAD-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHAE-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHAS-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LHAK-A	230 [J]	0.1 [m/s]	1.2 [m/s]
PHE27X30LMDD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMDE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMDS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMDK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMFD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMFE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMFS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMFK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMAD-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMAE-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMAS-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LMAK-A	210 [J]	0.8 [m/s]	2.2 [m/s]
PHE27X30LSDD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSDE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSDS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSDK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSFD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSFE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSFS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSFK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSAD-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSAE-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSAS-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LSAK-A	190 [J]	1.8 [m/s]	3.5 [m/s]
PHE27X30LWDD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWDE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWDS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWDK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWFD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWFE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWFS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWFK-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWAD-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWAE-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWAS-A	170 [J]	3 [m/s]	5 [m/s]
PHE27X30LWAK-A	170 [J]	3 [m/s]	5 [m/s]

螺纹: M33X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE33X15NHDD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHDE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHDS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHDK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHFD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHFE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHFS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHFK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHAD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHAE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHAS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHAK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHBS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NHBK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15NMDD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMDE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMDS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMDK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMFD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMFE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMFS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMFK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMAD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMAE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMAS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMAK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMBS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NMBK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15NSDD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSDE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSDS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSDK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSFD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSFE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSFS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSFK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSAD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSAE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSAS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSAK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSBS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NSBK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15NWDD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWDE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWDS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWDK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWFD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWFE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWFS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWFK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWAD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWAE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWAS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWAK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWBS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15NWBK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LHDD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHDE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHDS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHDK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHFD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHFE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHFS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHFK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHAD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHAE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHAS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LHAK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE33X15LMDD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMDE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMDS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMDK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMFD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMFE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMFS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMFK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMAD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMAE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMAS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LMAK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE33X15LSDD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSDE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSDS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSDK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSFD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSFE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSFS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSFK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSAD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSAE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSAS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LSAK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE33X15LWDD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWDE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWDS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWDK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWFD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWFE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWFS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWFK-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWAD-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWAE-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWAS-A	280 [J]	3 [m/s]	5 [m/s]
PHE33X15LWAK-A	280 [J]	3 [m/s]	5 [m/s]

螺纹: M36X1.5
订单号	连续运作时每行程最大能量吸收	最小撞击速度	最大撞击速度
PHE36X15NHDD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHDE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHDS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHDK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHFD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHFE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHFS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHFK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHAD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHAE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHAS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NHAK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15NMDD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMDE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMDS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMDK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMFD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMFE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMFS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMFK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMAD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMAE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMAS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NMAK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15NSDD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSDE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSDS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSDK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSFD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSFE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSFS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSFK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSAD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSAE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSAS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NSAK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15NWDD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWDE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWDS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWDK-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWFD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWFE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWFS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWFK-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWAD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWAE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWAS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15NWAK-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LHDD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHDE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHDS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHDK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHFD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHFE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHFS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHFK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHAD-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHAE-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHAS-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LHAK-A	400 [J]	0.1 [m/s]	1.2 [m/s]
PHE36X15LMDD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMDE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMDS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMDK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMFD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMFE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMFS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMFK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMAD-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMAE-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMAS-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LMAK-A	360 [J]	0.8 [m/s]	2.2 [m/s]
PHE36X15LSDD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSDE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSDS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSDK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSFD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSFE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSFS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSFK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSAD-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSAE-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSAS-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LSAK-A	320 [J]	1.8 [m/s]	3.5 [m/s]
PHE36X15LWDD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWDE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWDS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWDK-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWFD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWFE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWFS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWFK-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWAD-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWAE-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWAS-A	280 [J]	3 [m/s]	5 [m/s]
PHE36X15LWAK-A	280 [J]	3 [m/s]	5 [m/s]

工业缓冲器 PowerStopHigh Energy 系列

工业缓冲器 PowerStop
High Energy 系列
